GF 229HTR WallMark Canvas – 150mic Matt White Embossed Wall/Floor Vinyl Clear High-Tack Removable Adhesive


GF 229HTR WallMark Canvas is a 150mic matt white embossed wall/floor vinyl with a clear high-tack removable adhesive.

It’s an ideal wall covering material for most types of surfaces including smooth painted interior walls and moderately textured surfaces. Additionally, it is slip rated to R10 certification making it great for temporary floor graphics too! Fire rated to B1 certification. Suitable for use on Solvent, Latex and UV-C printers.

Order by 4:00PM for
next day delivery
00hrs 00mins 00seconds


This product is only available to printers and signmakers
Log-in to your account Sign-up for an account

Product Information

Expand all

Description

GF 229HTR WallMark Canvas is a 150mic matt white embossed wall/floor vinyl with a clear high-tack removable adhesive.

It’s an ideal wall covering material for most types of surfaces including smooth painted interior walls and moderately textured surfaces. Additionally, it is slip rated to R10 certification making it great for temporary floor graphics too! Fire rated to B1 certification. Suitable for use on Solvent, Latex and UV-C printers.

Printing & Application Guidelines

Completely evaporate inkjet solvents before application. Failure to do so may facilitate solvent penetration resulting in vinyl degradation.

229HTR Series can be used in applications where a conformable removable vinyl is desired . It is designed for wall murals, floor applications, decals and graphics to most types of smooth painted interior walls. This includes most flat, semi-gloss and gloss paint finishes. The surface must be smooth and clean prior to application. If applying to new paint consult the paint manufacturer for proper drying conditions before Concept® 229 application. Not designed for coated/sealed/treated stainless steel, brass or bronze surfaces. The material does have a R10B certification and can be used in barefoot and wet areas.

Product Chart

Film Film Type White Polymeric Vinyl
Film Thickness (μm) 152
Film Weight (gsm) 240
Gloss (60°) <20
Opacity (%) 98
Tensile Strength (lbs/in) MD > 2500 / CD > 2000
Elongation (%) MD > 70 / CD > 130
Dimensional Stability (FTM 14) MD < 0.30 mm / CD < 0.20 mm
Adhesive Adhesive Type Solvent Acrylic
Adhesive Thickness (μm) 18-25
Adhesive Color Clear
Peel Strength on Stainless Steel (N/25mm) 15 min 4.4
Peel Strength on Stainless Steel (N/25mm) 24 hrs 6.1
Liner Liner Weight (gsm) 145
Liner Type White 2-Sided PE Coated Kraft
Liner Thickness (μm) 170
Release Force @ 300” / min (g/2”) 300-450
Performance Guidance Application Temperature > +4.4 °C
Service Temperature -40 °C to 82.2 °C
Shelf Life 1 year
Storage Temp / Rel. Humidity 21.1 °C / 50%
Outdoor Durability 3 years
Indoor Durability 5 Years
Removability 1 year
Flammability Flammability ASTM E84 Class 1 or A (Rating Standard Test Method for Surface Burning Characteristics of Building Materials)
