Clear Adhesive5-7 Year Polymeric VinylsGeneral Formulations

General Formulations 235 MotoMark – 100mic Matt White “GRIP” Vinyl, High Bond Adhesive


GF 235 MotoMark is a 100mic matt white vinyl with a high bond adhesive.

Designed for applications where a flexible premium film with super high bond adhesion is required. We recommend using this vinyl for demanding applications such as, Quads, Motorbikes, Snowmobiles, Helmets, and Carts. Suitable for use on Solvent, Latex and UV-C printers.

Order by 4:00PM for
next day delivery
00hrs 00mins 00seconds


This product is only available to printers and signmakers
Log-in to your account Sign-up for an account

Product Information

Expand all

Description

235 Series MotoMark™ 100 mic “GRIP” is specially formulated premium flexible matte white PVC film. This film has a unique “High Bond” acrylic pressure sensitive adhesive with a 135 gsm layflat liner. The adhesive is formulated for the powersport graphic and decal markets. 235 Series MotoMark™ can be printed on a variety of solvent-based, latex, UV and thermal printers that are commonly used in wide format. This product may also be printed on using other printing processes such as UV screen and UV curable offset but must be tested before production.

Printing & Application Guidelines

235 Series MotoMark™ is designed for applications where a flexible premium film with special high bond adhesion is required. Concept®235 MotoMark™ is recommended for applications such as, Quads, Snowmobiles, Motocross, Powersport Vehicles, Helmets, and Carts. Testing is always suggested before application.

Recommended to use Concept® 238 MotoMark™ 300 mic “ARMOR” Gloss Clear UV overlaminate. This will add ultimate protection, performance and durability to the graphic or decal.

Completely evaporate inkjet solvents before application. Failure to do so may facilitate solvent penetration resulting in vinyl degradation. Always thoroughly test this product to confirm that it meets your requirements. Proper surface preparation requires cleaning with alcohol or acetone to clean and remove contaminates before application. Failure to prepare the surface can cause premature failure of the graphic or decal.

Product Chart

Film Film Type White Polymeric Vinyl
Film Thickness (μm) 86
Film Weight (gsm) 120
Gloss (60°) > 20
Opacity (%) > 93
Tensile Strength (lbs/in) MD > 3000 / CD > 2600
Elongation (%) MD > 90 / CD > 150
Dimensional Stability (FTM 14) MD < 1.0 mm / CD < 0.50 mm
Adhesive Adhesive Type Solvent Acrylic
Adhesive Thickness (μm) 45-56
Adhesive Color Clear
Peel Strength on Stainless Steel (N/25mm) 15 min 26
Peel Strength on Stainless Steel (N/25mm) 24 hrs 26
Liner Liner Weight (gsm) 145
Liner Type White 2-sided PE-Coated Kraft
Liner Thickness (gsm) 170
Release Force @ 300” / min (g/2”) 35-55
Performance Guidance Application Temperature > +4.4 °C
Service Temperature -40 °C to 82.2 °C
Shelf Life 6 months
Storage Temp / Rel. Humidity 21.1 °C / 50%
Outdoor Durability 5 years
